JETBROACH Tungsten Carbide Tipped Annular Cutter
JETBROACH One-Touch Type
Dia. x depth 35 mm Dia. x depth 50 mm 17.5 x 35 17.5 x 50 18 x 35 18 x 50 18.5 x 35 - 19 x 35 19 x 50 19.5 x 35 19.5 x 50 20 x 35 20 x 50 20.5 x 35 20.5 x 50 21 x 35 21 x 50 21.5 x 35 21.5 x 50 22 x 35 22 x 50 22.5 x 35 22.5 x 50 23 x 35 23 x 50 - 23.5 x 50 24 x 35 24 x 50 24.5 x 35 24.5 x 50 25 x 35 25 x 50 26 x 35 26 x 50 26.5 x 35 26.5 x 50 27 x 35 27 x 50 28 x 35 28 x 50 29 x 35 29 x 50 30 x 35 30 x 50 31 x 35 31 x 50 32 x 35 32 x 50 33 x 35 33 x 50 34 x 35 34 x 50 34.5 x 35 - 35 x 35 35 x 50 36 x 50 37 x 50 38 x 50 39 x 50 40 x 50 41 x 50 42 x 50 43 x 50 44 x 50 45 x 50 46 x 50 47 x 50 48 x 50 49 x 50 50 x 50 Pilot Pin : N8 x 35 Pilot Pin : N8 x 50
Dia. x depth 75 mm 51 x 75 52 x 75 53 x 75 54 x 75 55 x 75 56 x 75 57 x 75 58 x 75 59 x 75 60 x 75 61 x 75 62 x 75 63 x 75 64 x 75 65 x 75 66 x 75 67 x 75 68 x 75 69 x 75 70 x 75 71 x 75 72 x 75 73 x 75 74 x 75 75 x 75 76 x 75 77 x 75 78 x 75 79 x 75 80 x 75 81 x75 82 x75 83 x 75 84 x 75 85 x 75 86 x 75 87 x 75 88 x 75 89 x 75 90 x 75 91 x 75 92 x 75 93 x 75 94 x 75 95 x 75 96 x 75 97 x 75 98 x 75 99 x 75 100 x 75 Pilot pin : N12075 HI-BROACH High Speed Steel Annular Cutter
(Resharpening Service is available)HI-BROACH One-Touch Type
Dia. x depth 25 mm Dia. x depth 50 mm 12 x 25 12 x 50 13 x 25 13 x 50 14 x 25 14 x 50 15 x 25 15 x 50 16 x 25 16 x 50 17 x 25 17 x 50 17.5 x 35 - 18 x 35 18 x 50 19 x 35 19 x 50 19.5 x 35 - 20 x 35 20 x 50 21 x 35 21 x 50 21.5 x 35 - 22 x 35 22 x 50 22.5 x 35 - 23 x 35 23 x 50 23.5 x 25 - 24 x 35 24 x 50 24.5 x 35 - 25 x 35 25 x 50 26 x 35 26 x 50 26.5 x 35 - 27 x 35 27 x 50 28 x 35 28 x 50 29 x 35 29 x 50 30 x 35 30 x 50 31 x 35 31 x 50 32 x 35 32 x 50 Pilot Pin (Dia. 12 - 17 mm) : H6 x 25 Pilot Pin (Dia. 12 - 17 mm) : H6 x 50 Pilot Pin (Dia. 17.5 - 32 mm) : H8 x 25 Pilot Pin (Dia. 17.5 - 32 mm) : H8 x 50
